CABLE DISPLAY PORT 10M/38520 LINDY
-
Pick up from the Woodmart Store
To pick up today
Free
-
Courier delivery
Our courier will deliver to the specified address
2-3 Days
From $40
-
DHL Courier delivery
DHL courier will deliver to the specified address
1-2 Days
From $40
161.47 €
Neturime
Neturime
Description
Compliance certificates
CE/Federal Communications Commission (FCC)/REACH/RoHS/UKCA
Lindy’s range of Fibre Optic Hybrid cables are a professional solution for extending DP signals over longer distances.Combining the flexibility and high EMI and RFI resistance of fibre optic cable with standard copper cabling, these hybrid cables are ideal for use in critical AV setups, commercial displays or high-performance residential installations.
The internal technology provides uncompressed amplification of the DP signal, allowing long distance extension of DP 8K content that is simply not possible with passive cables.
With 40Gbps bandwidth (UHBR10), these cables support DisplayPort 2.0 resolutions up to 3840×2160@144Hz, and 7680×4320 / 10240×4320@60Hz. Content can be viewed with incredible detail and clarity at higher refresh rates and supporting static and dynamic HDR for optimum viewing of movies, graphics or imagery.
- Combines copper and fibre optic cable for a hybrid, long distance DisplayPort connectivity solution
- Supports resolutions up to 4K@144Hz, 8K@60Hz
- DP2.0 standard with UHBR10 support, 40Gbps bandwidth (4 lanes, 10Gbps per channel)
- Flexible and robust cable structure for any kind of installations
- 2-Year Warranty
Specifikacijos
| Vendor Homepage | https://www.lindy.co.uk/cables-adapters-c1/audio-video-c107/10m-fibre-optic-hybrid-dp-2-0-uhbr10-cable-p14673 |
|---|---|
| Category Code | CDP |
| Unit Box Height | 0.07 |
| Unit Box Length | 0.245 |
| Unit Box Width | 0.24 |
| AWG wire size | 24 |
| Cable length | 10 m |
| Cable material | Fibre optic/Copper |
| Cable type | Round cable |
| Connector 1 | DisplayPort |
| Connector 1 form factor | Straight |
| Connector 1 gender | Male |
| Connector 2 | DisplayPort |
| Connector 2 form factor | Straight |
| Connector 2 gender | Male |
| Connector contacts plating | Gold |
| Connector housing material | PVC |
| Data transfer rate | 40 Gbit/s |
| DisplayPort version | 2.0 |
| Jacket material | Polyvinyl chloride (PVC) |
| Maximum refresh rate | 144 Hz |
| Maximum resolution | 7680 x 4320 pixels |
| Product colour | Black |
| Operating temperature (T-T) | -10 – 60 °C |
| Storage temperature (T-T) | -20 – 70 °C |
| Certification | California Proposition 65 |
| Sustainability compliance | Yes |
| Cable diameter | 4 mm |
| Connector 1 dimensions (WxDxH) | 19.8 x 47.8 x 12 mm |
| Package type | Box |
| Warranty period | 2 year(s) |
| Model | 38520 |
| Units per Shipping Box | 1 |
| Unit Calculated Volume | 0.004116 cubm |
| Unit Calculated Weight | 0.394 kg |
