NET CAMERA 5MP EYEBALL/HDW5559TM-ASE-IL-0360B DAHUA

Produkto kodas: 1459801

Pick up from the Woodmart Store

To pick up today

Courier delivery

Our courier will deliver to the specified address

2-3 Days

From $40

DHL Courier delivery

DHL courier will deliver to the specified address

1-2 Days

From $40

Original price was: 350.28 €.Current price is: 161.13 €.

Liko 4

Description

White balance

Auto/Manual/Natural/Outdoor/Regional custom/Street lamp

Supported network protocols

IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP; P2P; Auto Registration

Intelligent Video Surveillance (IVS) system features

Face detection/Heat map/Human detection/Intrusion/People counting/Tripwire

5-MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.
Outputs max. 5 MP (2960 × 1668) @25/30 fps.
Built-in multi-core light, the max. IR distance is 50 m and the max. warm light distance is 50 m.
ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
Powered by the Xinghan Large-Scale AI Models-Vision, the camera outstandingly delivers on its object detection, recognition, and scene adaptation functions.
With deep learning algorithm, it supports: AcuPick, video metadata, IVS, face detection, and people counting, etc.
Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 1 TB Micro SD card; built-in Mic
12 VDC/PoE power supply; ePoE
IP67 protection.

Dahua Technology WizMind IPC-HDW5559TM-ASE-IL. Type: IP security camera, Placement supported: Outdoor, Connectivity technology: Wired. Mounting type: Ceiling, Product colour: White, Form factor: Turret. Minimum illumination: 0.0005 lx, Angle of rotation: 360°, Lens viewing angle, horizontal: 108.4°. Sensor type: CMOS, Optical sensor size: 25.4 / 2.7 mm (1 / 2.7″). Detect distance: 124 m, Observe distance: 49.6 m, Recognize distance: 24.8 m

Specifikacijos

Vendor Homepage	https://www.dahuasecurity.com/ceen/products/All-Products/Network-Cameras/WizMind-5-Series/Smart-Dual-Light/5MP/IPC-HDW5559TM-ASE-IL
Category Code	FNC
Unit Box Height	0.14
Unit Box Length	0.14
Unit Box Width	0.15
Form factor	Turret
Housing material	Metal
International Protection (IP) code	IP67
Mounting type	Ceiling
Product colour	White
Alarm input/output	Yes
Connectivity technology	Wired
Day/night mode	Yes
Dynamic range	56 dB
People counting function	Yes
Placement supported	Outdoor
Type	IP security camera
Wide Dynamic Range (WDR)	Yes
Angle of rotation	360 °
Camera pan control	Yes
Camera shutter speed	1/3 – 1/100000 s
Camera shutter type	Electronic
Camera tilt control	Yes
Lens viewing angle, diagonal	127.1 °
Lens viewing angle, horizontal	108.4 °
Lens viewing angle, vertical	60 °
Minimum illumination	0.0005 lx
Pan range	0 – 360 °
Tilt angle range	0 – 80 °
Optical sensor size	1/2.7 "
Progressive scan	Yes
Sensor type	CMOS
Closest focusing distance	3.2 m
Detect distance	124 m
Fixed focus	Yes
Focal length range	6 – 2.8 mm
Identify distance	12.4 m
Maximum aperture number	1.6
Observe distance	49.6 m
Recognize distance	24.8 m
LED type	IR/White
Night vision	Yes
Night vision distance	50 m
Back Light Compensation (BLC)	Yes
Bit rate control	Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Frame rate	30 fps
Gain control type	Auto/Manual
Highlight Compensation (HLC)	Yes
Maximum resolution	2960 x 1668 pixels
Noise reduction	Yes
Noise reduction technology	3D noise reduction
Privacy masking	Yes
Region of Interest (ROI) encoding	Yes
Total megapixels	5 MP
Video compression formats	H.264/H.264B/H.264H/H.265/M-JPEG
Video streaming	Yes
Audio formats supported	G.711 µ-law/G.711 A-law/G.723/G.726/PCM
Audio input channels	1.0 channels
Audio output channels	1.0 channels
Built-in microphone	Yes
Bluetooth	No
Ethernet LAN	Yes
Number of users	20 user(s)
Quality of Service (QoS) support	Yes
Streaming method	Multicast
Wi-Fi	No
Built-in HDD	No
Card reader integrated	Yes
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	1000 GB
RAM capacity	2000 MB
ROM capacity	4000 MB
Ethernet LAN (RJ-45) ports	1
Alarm input channels	1
Alarm output channels	1
Digital watermark	Yes
HTTPS encryption	Yes
Human and vehicle targets classification	Yes
Mirror	Yes
Network access storage (NAS)	Yes
Video motion detection	Yes
Cloud-managed	No
DC output voltage	12
Power consumption (max)	13.3 W
Power consumption (Power over Ethernet (PoE))	6.3 W
Power consumption (typical)	4.2 W
Power source type	DC,PoE
Operating relative humidity (H-H)	0 – 95 %
Operating temperature (T-T)	-40 – 60 °C
Storage temperature (T-T)	-40 – 60 °C
Mobile operating systems supported	Android/iOS
Diameter	122 mm
Height	105.5 mm
Weight	530 g
Compliance certificates	CE/Electromagnetic Compatibility (EMC)
Package type	Box
Package weight	710 g
Manual	Yes
Number of cameras	1
Audio input	RCA
Audio output	RCA
Browser supported	IE: IE 11, Chrome: Chrome 102, Firefox: Firefox 88
Lens mount interface	M12
Number of video streams	4
Units per Pallet	0
Units per Shipping Box	1
Unit Calculated Volume	0.00294 cubm
Unit Calculated Weight	0.78 kg
