Description
The Anthra Line USB 2.0 Type C to B cables from Lindy’s Cable Lines concept are the professional choice for high performance connections in commercial AV and IT installations.
They are premium connections that feature double shielded construction with tinned copper conductors for performance and corrosion resistance. High quality gold plated contacts and nickel plated connectors maintain optimal signal integrity and maximum reliability.
Data transfer speeds up to 480Mbps are supported for the quick and effortless transfer of large data volumes.
USB Type C features a reversible connector, so no matter which orientation the cable is inserted, a connection will always be found. This connector allows a fully bi-directional cable with automatic host and device negotiation.
Anthra Line USB 2.0 Type C to B cables are available in the following length: 0.5m, 1m, 2m and 3m.
- Professional choice USB 2.0 Type C to B cable for commercial and high performance AV and IT installations
- Supports data transfer speeds up to 480Mbps
- Robust PVC housing, nickel connectors and gold plated contacts
- Double shielded cable, corrosion resistant tinned copper conductors
- 10 year warranty
Specifikacijos
| Vendor Homepage | https://www.lindy.co.uk/cables-adapters-c1/usb-c449/0-5m-usb-2-0-type-c-to-b-cable-anthra-line-p14243 |
|---|---|
| Category Code | UCB |
| Unit Box Height | 0.01 |
| Unit Box Length | 0.11 |
| Unit Box Width | 0.1 |
| Bend radius (min) | 25 mm |
| Cable diameter | 4.4 mm |
| Cable length | 0.5 m |
| Connector 1 dimensions (WxDxH) | 10.9 x 28.3 x 7.2 mm |
| Connector 2 dimensions (WxDxH) | 11.8 x 47 x 10.2 mm |
| AWG wire size | 26/28 |
| Cable jacket material | Nylon/Polyvinyl Chloride (PVC) |
| Cable type | Round cable |
| Conductor material | Tinned copper |
| Connector 1 | USB C |
| Connector 1 form factor | Straight |
| Connector 1 gender | Male |
| Connector 2 | USB B |
| Connector 2 form factor | Straight |
| Connector 2 gender | Male |
| Connector contacts plating | Nickel |
| Connector shield material | Aluminium |
| Connector shielding | Yes |
| Maximum data transfer rate | 480 Mbit/s |
| Nominal attenuation | 1 – 400MHz < 5.8dB |
| Product colour | Black |
| USB version | USB 2.0 |
| Package type | Polybag |
| Quantity per pack | 1 pc(s) |
| Operating temperature (T-T) | 0 – 40 °C |
| Storage temperature (T-T) | 0 – 70 °C |
| Certification | RoHS, REACH, California Proposition, UL |
| Harmonized System (HS) code | 84733080 |
| Model name | 0.5m USB 2.0 Type C to B Cable, Anthra Line |
| Units per Shipping Box | 1 |
| Unit Calculated Volume | 0.00011 cubm |
| Unit Calculated Weight | 0.03 kg |
